Locking GDS® Dock + USB-A & RJ45 for Zebra ET401 8″ with IntelliSkin®
$386.49
Available on backorder
Available on backorder
Available on backorder
Overview
The Locking GDS Power + Dual USB-A & RJ45 Dock for Zebra ET4x 8″ with IntelliSkin (RAM-GDS-DOCKL-ZE20-RJ45AU) features GDS Technology for data and charging capabilities and a key lock for theft deterrence, the GDS Vehicle Dock for Zebra ET40 & ET45 8″ enterprise tablets with IntelliSkin Next Generation protective sleeve allows you to connect one peripheral and maintain a secure internet connection while keeping the device charged through the pogo pin contacts when the device is docked. Power is provided by connecting to the dock’s USB Type-C connector, while peripheral support is provided by the built-in dual USB Type-A and RJ45 (ethernet) cord. The dock also allows the tablet’s scanning function to work on the side, as well as tablet add-ons such as the Zebra Expansion Back and PowerPack Battery. This vehicle dock is compatible with C and D size RAM 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm in order to complete your mounting solution. Take the solution a step further by taking advantage of the built-in 2-hole mounting plate compatible with RAM 2-hole diamond base for additional device mounting such as a phone or other handheld device. Always Protected. Always Connected.
Features
- Locking powered dock featuring GDS® Technology™ with data and charging capabilities for the Zebra ET40 & ET45 8" tablets with IntelliSkin® Next Gen protective sleeve via USB Type-C for power and dual USB Type A & RJ45 (ethernet) connector; MIL-STD 810G Shock and Vibration tested
- When connected to a power source, integrated pogo pins provide power to the device while docked; Dock accommodates tablet add-ons such as the Expansion Back and PowerPack Battery; tablet scanning works while tablet is docked
- Compatible with C and D size RAM® 4-hole AMPS and 75mm x 75mm VESA pattern bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
- Built-in 2-hole mounting plate for additional device mounting such as a phone; compatible with RAM® 2-hole diamond bases and accessory side bracket
- Backed by a 3-year warranty
Compatibility
Compatible Devices
- Zebra ET40 8" Tablet with IntelliSkin® Next Gen
- Zebra ET45 8" Tablet with IntelliSkin® Next Gen
Specs
| Weight | 1.69 lbs |
|---|---|
| Product Weight | |
| Hardware Included | (1) Side bracket for accessory mounting, (2) #8-32 x 1/2" Machine Screws, (2) Keys, (2) Small Cable Ties, (4) #10-24 Nylock Nuts, (4) #10-24 x 5/8" Machine Screws, (4) #8-32 x 5/8" Machine Screws, (6) #8-32 Nylock Nuts |
| Hole Pattern | |
| Materials | |
| Packaging Type | |
| Output Voltage | mUSB Tablets: 5V @ 1.5A max, Type-C Tablets: 5V – 12V @ 3A max |
| Power Output | |
| Input Connector | |
| Input Cable Length | |
| Output Connector | |
| Output Cable Length | |
| Peripheral Output |
