Samsung Galaxy Tab A11+ Uni-Conn Locking Bundle RAM-GDS-U4-SAM88-1-KIT2
The RAM-GDS-U4-SAM88-1-KIT2 is a GDS® Uni-Conn™ Locking Vehicle Bundle designed for the Samsung Galaxy Tab A11+. This A11+ Uni-Conn Locking Bundle combines the compatible IntelliSkin® Next Gen sleeve, key-locking Uni-Conn dock, Uni-Conn adapter, vehicle hardwire charger, and C Size mounting components into one vehicle deployment package.
The dock uses a USB Type-C female power connector and integrated pogo pins to provide power to the tablet while docked. A quick-release button supports tablet removal, while the dock’s key lock and the locking knob on the mounting arm provide additional theft deterrence.
What Is the RAM-GDS-U4-SAM88-1-KIT2?
The RAM-GDS-U4-SAM88-1-KIT2 is a complete GDS® Uni-Conn™ locking vehicle bundle for the Samsung Galaxy Tab A11+.
The bundle includes:
- GDS® Uni-Conn™ key-locking dock with quick-release button
- GDS® Uni-Conn™ adapter
- IntelliSkin® Next Gen for Samsung Tab A11+
- C Size double ball mount with medium arm
- Backing plate adapter
- 10-30V hardwire charger
- USB-A male to USB-C male 2.0 extension cable
- Cable clamp
- Assembly hardware
- Two keys
The complete package is designed to provide the main components needed to deploy the compatible tablet in a fleet vehicle.
Key Features of the A11+ Uni-Conn Locking Bundle
Key-Locking Uni-Conn Dock
The included GDS® Uni-Conn™ dock uses a key-locking design. RAM Mounts states that the dock’s key lock and the locking knob on the arm provide additional theft deterrence.
The bundle includes two keys for the locking system.
Quick-Release Button
The Uni-Conn dock features a quick-release button for tablet removal. The docking process places the IntelliSkin-wrapped tablet into the dock and pushes it into position. Pressing the quick-release button frees the tablet for undocking.
Integrated Pogo-Pin Charging
The dock uses integrated pogo pins to provide power to the tablet while docked. Power connects to the dock through its USB Type-C female connector.
IntelliSkin Next Gen
The bundle includes IntelliSkin® Next Gen for Samsung Tab A11+. The sleeve interfaces with the included Uni-Conn adapter and dock as part of the vehicle deployment system.
C Size Medium-Arm Mount
The bundle includes a C Size (1.5″) double ball mount with a medium arm. The official specification lists a 4.66″ socket-to-socket length.
Compatibility
The RAM-GDS-U4-SAM88-1-KIT2 is compatible with:
- Samsung Galaxy Tab A11+
- Samsung Galaxy Tab A11+ with the included IntelliSkin® Next Gen
The official RAM Mounts compatibility listing identifies the Galaxy Tab A11+ as the compatible device.The product should therefore be presented specifically as an A11+ vehicle bundle rather than as a universal Samsung tablet mounting solution.
How the Uni-Conn Locking Vehicle Bundle Works
The Samsung Galaxy Tab A11+ is used with the included IntelliSkin® Next Gen sleeve. The IntelliSkin-wrapped tablet is placed into the base of the GDS® Uni-Conn™ dock and pushed into position until it snaps into place.
Integrated pogo pins provide power to the device while docked. The dock receives power through its USB Type-C female power connector and connects to the included vehicle hardwire charger.
For removal, the quick-release button releases the tablet from the dock. The key-locking mechanism and locking knob provide the additional theft-deterrence feature specified by RAM Mounts.
Vehicle Mounting Configuration
The RAM-GDS-U4-SAM88-1-KIT2 includes a C Size mounting system with a medium arm. The double ball design connects the docking assembly to the supplied backing plate and vehicle mounting components.
The kit includes a 2.10″ x 2.60″ steel backing plate, four #8-32 x 1″ screws, four #8 flat washers, four #8 split lock washers, and assembly hardware.
A cable clamp and USB cable are also included as part of the bundle.
Power and Charging
The vehicle hardwire charger accepts a 10-30VDC input. The current official RAM Mounts specification lists 5-15V output at 3A and a 45W power output.
The dock uses a USB Type-C female power connector and integrated pogo pins for supplying power to the docked Samsung Galaxy Tab A11+.
The supplied product information lists a 5-9VDC output, so the difference between the supplied specification and the current official specification should be considered when publishing the final product data.
Technical Specifications
| Specification | Details |
| SKU | RAM-GDS-U4-SAM88-1-KIT2 |
| Product Type | GDS® Uni-Conn™ Locking Vehicle Bundle |
| Compatible Device | Samsung Galaxy Tab A11+ |
| IntelliSkin | IntelliSkin® Next Gen for Samsung Tab A11+ |
| Dock | GDS® Uni-Conn™ Locking Dock with Release Button |
| Dock Lock | Key lock |
| Mount Arm | C Size Medium |
| Ball Size | C Size (1.5″) |
| Socket-to-Socket Length | 4.66″ |
| Weight | 3.4 lb |
| Materials | Steel, marine-grade aluminum, high strength composite |
| Packaging | Poly Bag |
| Input Voltage | 10-30VDC |
| Official Output Voltage | 5-15V @ 3A |
| Official Power Output | 45W |
| Output Current | 2.5A max |
| Operating Temperature | -10°C to +70°C |
| Storage Temperature | -40°C to +70°C |
| Regulatory | Over Voltage Protection, Short Circuit Protection, Reverse Polarity Protection, RoHS Compliance, WEEE Compliance, SAE J-1113-5 Load Dump, Moisture Resistant, FCC, CE, UKCA, IC |
| Certifications | E-Mark Certification, RCM Certification, IEC/UL 62368-1 |
| Warranty | 3 years |
Hardware Included
The RAM-GDS-U4-SAM88-1-KIT2 includes:
- Assembly hardware
- Two keys
- 2.10″ x 2.60″ steel backing plate
- Four #8-32 x 1″ screws
- Four #8 split lock washers
- Four #8 flat washers
- Cable clamp
- USB cable
- Vehicle hardwire charger
Why Choose the RAM-GDS-U4-SAM88-1-KIT2?
This bundle combines the docking, locking, tablet interface, power, and vehicle mounting components for a Samsung Galaxy Tab A11+ deployment.
Verified features include:
- Key-locking GDS® Uni-Conn™ dock
- Quick-release button
- Integrated pogo-pin power connection
- IntelliSkin® Next Gen for Samsung Tab A11+
- C Size (1.5″) double ball mount with medium arm
- Locking knob on the mounting arm
- 10-30VDC vehicle hardwire charger
- Included backing plate and mounting hardware
- Two keys
- 3-year warranty
The locking dock and mounting-arm locking knob distinguish this bundle from the non-locking Uni-Conn vehicle bundle for the same tablet model.
Frequently Asked Questions
RAM-GDS-U4-SAM88-1-KIT2 is a GDS® Uni-Conn™ Locking Vehicle Bundle for the Samsung Galaxy Tab A11+. It includes the locking dock, IntelliSkin Next Gen, Uni-Conn adapter, C Size mounting components, vehicle hardwire charger, and related hardware.
The bundle is compatible with the Samsung Galaxy Tab A11+. RAM Mounts specifically lists the Galaxy Tab A11+ under compatibility for this SKU.
Yes. The bundle includes a key-locking GDS® Uni-Conn™ dock. RAM Mounts also specifies a locking knob on the mounting arm.
Yes. The dock uses integrated pogo pins to provide power to the tablet while docked and connects to power through a USB Type-C female connector.
The Uni-Conn dock features a quick-release button. Pressing the button releases the IntelliSkin-wrapped tablet from the dock.
The bundle includes a C Size (1.5″) double ball mount with a medium arm and a listed 4.66″ socket-to-socket length.
