Single USB-C Uni-Conn Dock RAM-GDS-DOCK-U1CP-CU
The GDS® Uni-Conn™ Dock + Single USB-C with Release Lever provides a snap-in docking solution for compatible IntelliSkin®-wrapped devices. With the RAM-GDS-DOCK-U1CP-CU, this GDS Uni-Conn dock combines pogo-pin charging with a USB Type-C female connection that supports one peripheral device.
The dock requires the GDS Uni-Conn Adapter RAM-GDS-U1U on the intended IntelliSkin-wrapped device. Its fixed-height design supports a defined group of Samsung tablets, while the integrated release lever provides a straightforward way to undock the tablet.
What Is the RAM-GDS-DOCK-U1CP-CU?
The RAM-GDS-DOCK-U1CP-CU is a GDS Uni-Conn powered docking platform with a single USB-C peripheral connection. It uses an integrated pogo-pin connector to provide charging to a compatible IntelliSkin-wrapped device.
The dock also includes a USB Type-C female connection. This connection provides the dock’s power input and allows one additional USB-C peripheral device to connect to the docking solution.
The docking process is designed around a snap-in connection. Place the IntelliSkin-wrapped device into the dock and push it into position. To undock the tablet, press the release lever.
Key Features of the Single USB-C Uni-Conn Dock
- Snap-in GDS Uni-Conn docking platform with an integrated pogo-pin connection.
- Designed for compatible devices wrapped in an IntelliSkin protective sleeve.
- Requires the GDS Uni-Conn Adapter RAM-GDS-U1U on the intended device.
- USB Type-C female connection supports one additional peripheral device.
- Release lever provides the dock’s quick-release function.
- High-strength composite construction.
- 2-hole AMPS mounting pattern measuring 1.912 inches.
- RAM Mounts Compatible.
- Backed by a 3-year warranty.
- Includes a lever stop that must be installed for the dock to function properly.
Compatibility
The RAM-GDS-DOCK-U1CP-CU has a fixed dock height and is currently listed as compatible with the following Samsung tablets:
- Samsung Tab A7 Lite
- Samsung Tab A 8.4
- Samsung Tab S9 FE
- Samsung Tab S9 FE+
- Samsung Tab Active5
- Samsung Tab Active3
- Samsung Tab A9+
Compatibility requires the intended device to use an IntelliSkin protective sleeve with the GDS Uni-Conn Adapter RAM-GDS-U1U installed.
This compatibility list should not be generalized to other tablets without confirmation from the applicable RAM Mounts compatibility information.
How the GDS Uni-Conn Dock Works
The dock connects to an IntelliSkin-wrapped device through the GDS Uni-Conn system. The required GDS Uni-Conn Adapter provides the connection point between the device setup and the docking platform.
When the tablet is placed into the dock, the integrated pogo pins connect with the compatible IntelliSkin setup to provide charging. The USB Type-C connection also provides the dock’s power input and allows one peripheral device to connect.
For docking, place the compatible IntelliSkin-wrapped tablet into the base and push it into the snap-in position. When the tablet needs to be removed, use the release lever.
Lever Stop Requirement
The included lever stop is required for the dock to function properly. The manufacturer’s warranty is void if the dock is used without the lever stop.
Single USB-C Peripheral Connection
One of the distinguishing features of this GDS Uni-Conn dock is its single USB-C peripheral connection.
The USB Type-C female connector supports one additional peripheral device while the dock provides the power connection for the docking system. The product therefore combines tablet docking with a dedicated USB-C peripheral connection in the same docking platform.
Technical Specifications
| Specification | Details |
| SKU | RAM-GDS-DOCK-U1CP-CU |
| Product Type | GDS Uni-Conn powered snap-in dock |
| Overall Width | 3.16″ |
| Overall Height | 8.44″ |
| Overall Depth | 3.03″ |
| Hole Pattern | 2-Hole AMPS, 1.912″ |
| Material | High-strength composite |
| Input Connector | USB Type-C |
| Peripheral Connection | USB Type-C for 1 peripheral |
| Input Cable Length | 215mm |
| Output Cable Length | 215mm |
| Peripheral Output | 500mA |
| Hardware Included | 1 Lever Stop, 2 #8-32 x 1″ Machine Screws, 2 #8-32 Nyloc Nuts, 1 Cable Clamp Kit |
| Packaging | Poly Bag |
| Warranty | 3 years |
Power Specifications
The current RAM Mounts specification lists:
- Output Voltage: 5V–20V @ 3A
- Power Output: 60W
- Peripheral Output: 500mA
These values should be used instead of the older/supplied 5V–12V @ 3A and 15W values unless The Mount Depot has a separate verified specification source that confirms the difference.
Why Choose This Uni-Conn Dock?
The RAM-GDS-DOCK-U1CP-CU brings several GDS Uni-Conn functions together in one docking platform. It supports compatible IntelliSkin-wrapped tablets, provides pogo-pin charging, offers a single USB-C peripheral connection, and uses a release lever for undocking.
Its fixed-height design and defined Samsung tablet compatibility also make it important to select the correct IntelliSkin and Uni-Conn configuration before deployment.
For installations using this dock, the GDS Uni-Conn Adapter RAM-GDS-U1U is a required part of the device setup.
Frequently Asked Questions
RAM-GDS-DOCK-U1CP-CU is the GDS Uni-Conn Dock + Single USB-C with Release Lever. It is a snap-in docking platform for compatible IntelliSkin-wrapped devices and includes one USB-C peripheral connection.
The current RAM Mounts compatibility information lists Samsung Tab A7 Lite, Tab A 8.4, Tab S9 FE, Tab S9 FE+, Tab Active5, Tab Active3, and Tab A9+ for this fixed-height dock.
Yes. The intended IntelliSkin-wrapped device must have the GDS Uni-Conn Adapter RAM-GDS-U1U installed.
Yes. The dock uses an integrated pogo-pin connection to provide charging to the compatible IntelliSkin-wrapped device.
The dock supports one additional peripheral device through its USB Type-C connection.
Yes. The included lever stop is required for the dock to function properly. The manufacturer’s warranty is void if the dock is used without the lever stop.
